Use a Raspberry Pi and a camera to detect and track a coloured object in real time with Python and OpenCV.
Every step includes a visual reference and a plain-language explanation, so you always know what to do next.
Flash Raspberry Pi OS, connect the camera module (or a USB webcam), and confirm it works with a quick test capture before writing any AI code.
Open a terminal on the Pi and install the OpenCV Python library, which handles image capture and processing for us.
pip install opencv-python numpyThis script captures live video, converts each frame to HSV colour space, filters for a chosen colour range, and draws a box around the largest matching object.
import cv2
import numpy as np
cap = cv2.VideoCapture(0)
# Example range: tune these for your object's colour (here: orange)
lower_color = np.array([5, 150, 150])
upper_color = np.array([15, 255, 255])
while True:
ret, frame = cap.read()
if not ret:
break
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
mask = cv2.inRange(hsv, lower_color, upper_color)
contours, _ = cv2.findContours(mask, cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE)
if contours:
largest = max(contours, key=cv2.contourArea)
if cv2.contourArea(largest) > 500:
x, y, w, h = cv2.boundingRect(largest)
cv2.rectangle(frame, (x, y), (x + w, y + h), (0, 255, 0), 2)
cv2.putText(frame, "Object", (x, y - 10),
cv2.FONT_HERSHEY_SIMPLEX, 0.6, (0, 255, 0), 2)
cv2.imshow("AI Object Detection", frame)
if cv2.waitKey(1) & 0xFF == ord('q'):
break
cap.release()
cv2.destroyAllWindows()Run the script, hold up an object matching the tuned colour range in front of the camera, and confirm a green bounding box tracks it as it moves.
Confirm the camera is enabled (raspi-config → Interface Options → Camera) and that no other program is currently using it.
Your object's colour range likely differs from the example — use an HSV colour picker tool to find the right lower/upper values for your object and lighting.
Lower the camera resolution, or run on a Raspberry Pi 4/5 for better performance — the Pi 3 can struggle with larger frame sizes.
